EO Sterilizer

EO Sterilizer

EO sterilizer applies ethylene oxide gas to perform fumigation sterilization on products in the sterilization vessel at a certain temperature, pressure and humidity. It is suitable for medical treatment and public health fields. Compare with traditional high-pressure steam sterilization, EO sterilization is advantageous in strong penetrating power, thorough sterilization, non-corrosive and non-harmful to products. EO sterilization is accessible at low temperature, pressure and humidity, plus ideal for products hard to be sterilized at high temperature.

Request a Quote
Technical specs
Items Parameters
Capacity 1-100m³
Operating temperature 30℃~60℃; adjustable
Temperature uniformity ±3℃ (unloaded state)
Operating pressure -80kPa - 80kPa; adjustable
Operating humidity 35%~85%; adjustable
EO gas concentration 300-1000mg/L
Sterilization time Depending on actual process
Forvacuum time Depending on actual process
Washing time Depending on actual process
Ventilation time Depending on actual process
Power supply 380V/50Hz
Equipment features
  • The sterilization vessel is heated by recirculating hot water, producing large heating area. Parallel grouping of three water channel as a group is adopted and each group is adjustable in water amount independently. This ensures high heating rate and sterilization efficiency effect from the structure.
  • An unique EO gasfication equipment is adopted to precisely control the temperature of EO gas entering the sterilization vessel. A special jacket is used to maintain consistent temperature of the pipe between gasifier and sterilization vessel. This helps to achieve full vaporization and better sterilization effect, as well as avoiding the sterilized items from contamination.
  • Sterilizing software supports WIN7 operating system, featuring real-time monitoring, reading, alarming and data tracking. Conforms to CE certification and GMP on-the-spot audit.
  • Perfect power failure protection function: in case of power failure, the door seal maintains inflated state to prevent the leakage of EO gas. And the software data will not loss.
Sterilization standard

Manufacturing standard: EN1422-2014 Manufacturing Requirements and Test Methods for Medical Ethylene Oxide Sterilizer Validation standard: ISO11135-2014 Sterilization of health-care products - Ethylene oxide - Requirements for the development, validation and routine control of a sterilization process for medical devices
